ECP4404T-4 Baldor Electric 75HP Electric Motor, Phase 3,

$( function() {$( "#accordion" ).accordion({heightStyle:"content", collapsible: true, active:false});} ); Specifications Catalog Number ECP4404T-4 Enclosure TEFC Frame 405T Frame Material Cast Iron Frequency 60.00 Hz Motor Letter Type Three Phase Output @ Frequency 75.000 HP @ 60 HZ Phase 3 Synchronous Speed @ Frequency 1200 RPM @ 60 HZ Voltage @ Frequency 460.0 V @ 60 HZ Haz Area Class and Group CLI GP A,B,C,D Haz Area Division Division II Agency Approvals CCSAUSEEV CURUSEEV Ambient Temperature 40 °C Auxiliary Box NO AUXILLARY BOX Base Indicator Rigid Bearing Grease Type Polyrex EM (-20F +300F) Constant Torque Speed Range 10-60 Current @ Voltage 87.000 A @ 460.0 V Design Code B Drip Cover No Drip Cover Duty Rating CONT Efficiency @ 100% Load 94.5 % Feedback Device NO FEEDBACK High Voltage Full Load Amps 87.0 a Heater Indicator No Heater Insulation Class B Inverter Code Inverter Ready KVA Code G Lifting Lugs Standard Lifting Lugs Motor Lead Quantity/Wire Size 3 @ 2 AWG Motor Type A40064M Mounting Arrangement F1 Number of Poles 6 Overall Length 38.20 IN Power Factor 85 Pulley End Bearing Type Ball Pulley Face Code Standard Service Factor 1.15 Shaft Diameter 2.875 IN Shaft Ground Indicator No Shaft Grounding Shaft Rotation Reversible Shaft Slinger Indicator Shaft Slinger Speed 1185 rpm Speed Code Single Speed Motor Standards NEMA Starting Method Direct on line Thermal Device - Bearing None Thermal Device - Winding None Haz Area Temp Code T3 Applications Features Nameplate Performance
